CYLINDER HEAD/VALVES
8-3
SERVICE INFORMATION
GENERAL
• This section covers service of the cylinder head, valves and camshaft.
• The camshaft and cylinder head services can be done with the engine installed in the frame.
• When disassembling, mark and store the disassembled parts to ensure that they are reinstalled in their original loca-
tions.
• Clean all disassembled parts with cleaning solvent and dry them by blowing them off with compressed air before
inspection.
• Camshaft lubricating oil is fed through oil passages in the cylinder head. Clean the oil passages before assembling cyl-
inder head.
• Be careful not to damage the mating surfaces when removing the cylinder head cover and cylinder head.
SPECIFICATIONS
Unit: mm (in)
TORQUE VALUES
ITEM STANDARD SERVICE LIMIT
Cylinder compression 1,304 kPa (13.3 kgf/cm
2
, 189 psi)
at 350 min
-1
(rpm)
–
Valve clearance IN 0.20 ± 0.03 (0.008 ± 0.001) –
EX 0.28 ± 0.03 (0.011 ± 0.001) –
Camshaft Cam lobe height IN 34.38 – 34.62 (1.354 – 1.363) 34.36 (1.353)
EX 33.86 – 34.10 (1.333 – 1.343) 33.84 (1.332)
Runout – 0.05 (0.002)
Oil clearance 0.020 – 0.062 (0.0008 – 0.0024) 0.10 (0.004)
Valve lifter Valve lifter O.D. 25.978 – 25.993 (1.0228 – 1.0233) 25.97 (1.022)
Valve lifter bore I.D. 26.010 – 26.026 (1.0240 – 1.0246) 26.04 (1.025)
Valve,
valve guide
Valve stem O.D. IN 3.975 – 3.990 (0.1565 – 0.1571) 3.965 (0.1561)
EX 3.965 – 3.980 (0.1561 – 0.1567) 3.955 (0.1557)
Valve guide I.D. 4.000 – 4.012 (0.1575 – 0.1580) 4.04 (0.159)
Stem-to-guide clearance IN 0.010 – 0.037 (0.0004 – 0.0015) 0.075 (0.0030)
EX 0.020 – 0.047 (0.0008 – 0.0019) 0.085 (0.0033)
Valve guide projection
above cylinder head
IN 17.1 – 17.4 (0.67 – 0.69) –
EX 13.3 – 13.6 (0.52 – 0.54) –
Valve seat width 0.90 – 1.10 (0.035 – 0.043) 1.5 (0.06)
Valve spring free length IN 40.19 (1.582) 39.4 (1.55)
EX 39.76 (1.565) 39.0 (1.54)
Cylinder head warpage – 0.10 (0.004)
Cylinder head mounting bolt 47 N·m (4.8 kgf·m, 35 lbf·ft) Apply molybdenum disulfide oil to the
threads and seating surface.
Camshaft holder flange bolt 12 N·m (1.2 kgf·m, 9 lbf·ft) Apply engine oil to the threads and
seating surface.
Cylinder head cover bolt 10 N·m (1.0 kgf·m, 7 lbf·ft)
Breather plate bolt 12 N·m (1.2 kgf·m, 9 lbf·ft) CT bolt/Apply a locking agent to the
threads.
PAIR check valve cover bolt 12 N·m (1.2 kgf·m, 9 lbf·ft) CT bolt
Cam sprocket bolt 20 N·m (2.0 kgf·m, 15 lbf·ft) Apply a locking agent to the threads.
Cam chain tensioner A pivot bolt 12 N·m (1.2 kgf·m, 9 lbf·ft) Apply a locking agent to the threads.
Cam chain tensioner B pivot bolt 20 N·m (2.0 kgf·m, 15 lbf·ft) Apply a locking agent to the threads.
Cam chain guide A bolt 12 N·m (1.2 kgf·m, 9 lbf·ft)
Bleeding joint 12 N·m (1.2 kgf·m, 9 lbf·ft) Apply a locking agent to the threads.
Spark plug 16 N·m (1.6 kgf·m, 12 lbf·ft)
