SERVICE INFORMATION
GENERAL
• Place the motorcycle on level ground before starting any work.
• Gasoline is extremely flammable and is explosive under certain conditions.
• Work in a well ventilated area. Smoking or allowing flames or sparks in the work area or where the gasoline is stored
can cause a fire or explosion.
• The exhaust contains poisonous carbon monoxide gas that may cause loss of consciousness and may lead to death.
Run the engine in an open area or with an exhaust evacuation system in and enclosed area.
SPECIFICATIONS
ITEM SPECIFICATIONS
Throttle grip freeplay 2 – 6 mm (1/16 – 1/4 in)
Spark plug NGK CR8EH-9
DENSO U24FER9
Spark plug gap 0.80 – 0.90 mm (0.031 – 0.035 in)
Valve
clearance
IN 0.20 ± 0.03 mm (0.008 ± 0.001 in)
EX 0.28 ± 0.03 mm (0.011 ± 0.001 in)
Engine oil
capacity
After draining 2.7 liter (2.9 US qt, 2.4 Imp qt)
After oil filter change 2.8 liter (3.0 US qt, 2.5 lmp qt)
Engine oil Suggested oil:
Honda "4-stroke motorcycle oil" or an equivalent
Oil recommendation:
API classification: SG or higher (except oils labeled as
energy conserving on the circular API service label)
Viscosity: SAE 10W-30
JASO T 903 standard: MA
Engine idle speed 1,300 ± 100 min
-1
(rpm)
Drive chain slack 20 – 30 mm (1.0 – 1.2 in)
Recommended brake fluid DOT 4
Clutch lever freeplay 10 – 20 mm (3/8 – 13/16 in)
Tire size Front 120/70ZR17M/C (58W)
Rear 160/60ZR17M/C (69W)
Tire brand Bridgestone Front BT–57F RADIAL U
Rear BT–57R RADIAL E
Michelin Front Pilot ROAD B
Rear Pilot ROAD A
Tire air
pressure
Driver only Front 250 kPa (2.50 kgf/cm
2
, 36 psi)
Rear 290 kPa (2.90 kgf/cm
2
, 42 psi)
Driver and
passenger
Front 250 kPa (2.50 kgf/cm
2
, 36 psi)
Rear 290 kPa (2.90 kgf/cm
2
, 42 psi)
Minimum tire tread depth Front 1.5 mm (0.06 in)
Rear 2.0 mm (0.08 in)
