FRONT WHEEL/SUSPENSION/STEERING
13-4
SERVICE INFORMATION
GENERAL
• When servicing the front wheel, fork or steering stem, support the motorcycle using a safety stand or hoist.
• A contaminated brake disc or pad reduces stopping power. Discard contaminated pads and clean a contaminated disc
with a high quality brake degreasing agent.
• After the front wheel installation, check the brake operation by applying the brake lever.
• Refer to the brake system information (page 15-4).
• Use only tires marked "TUBELESS" and tubeless valves on rim marked "TUBELESS TIRE APPLICABLE".
SPECIFICATIONS
Unit: mm (in)
TORQUE VALUES
ITEM STANDARD SERVICE LIMIT
Minimum tire tread depth – 1.5 (0.06)
Cold tire pres-
sure
Driver only 250 kPa (2.50 kgf/cm
2
, 36 psi) –
Driver and passenger 250 kPa (2.50 kgf/cm
2
, 36 psi) –
Axle runout – 0.2 (0.01)
Wheel rim runout Radial – 2.0 (0.08)
Axial – 2.0 (0.08)
Wheel balance weight – 60 g (2.1oz) max.
Fork Spring free length 328.5 (12.93) 321.9 (12.67)
Tube runout – 0.20 (0.008)
Recommended fork fluid Honda Ultra Cushion Oil 10W or equivalent –
Fluid level 149 (5.9) –
Fluid capacity 457 ± 2.5 cm
3
(15.5 ± 0.08 US oz, 16.1 ± 0.09 lmp oz)
–
Steering head bearing pre-load 8.8 – 13.7 N (0.9 – 1.4 kgf, 2.0 – 3.1 lbf) –
Handlebar holder bolt 27 N·m (2.8 kgf·m, 20 lbf·ft)
Steering stem nut 103 N·m (10.5 kgf·m, 76 lbf·ft) See page 13-38
Steering bearing adjustment nut lock nut – See page 13-38
Steering bearing adjustment nut – See page 13-38
Fork top bridge pinch bolt 22 N·m (2.2 kgf·m, 16 lbf·ft)
Fork bottom bridge pinch bolt 39 N·m (4.0 kgf·m, 29 lbf·ft)
Front axle bolt 59 N·m (6.0 kgf·m, 43 lbf·ft)
Front axle holder bolt 22 N·m (2.2 kgf·m, 16 lbf·ft)
Front brake disc mounting bolt 20 N·m (2.0 kgf·m, 14 lbf·ft) ALOC bolt; replace with a new one
Front fork bolt 22 N·m (2.2 kgf·m, 16 lbf·ft)
Fork socket bolt 20 N·m (2.0 kgf·m, 14 lbf·ft) Apply a locking agent to the threads
Front master cylinder holder bolt 12 N·m (1.2 kgf·m, 9 lbf·ft)
Clutch holder bolt 10 N·m (1.0 kgf·m, 7 lbf·ft)
Front brake caliper mounting bolt 30 N·m (3.1 kgf·m, 22 lbf·ft) ALOC bolt; replace with a new one
Front brake hose clamp bolt (CBF600S/N) 12 N·m (1.2 kgf·m, 9 lbf·ft) ALOC bolt; replace with a new one
Front brake hose bolt 10 N·m (1.0 kgf·m, 7 lbf·ft)
Front pulser ring bolt (CBF600SA/NA) 7.0 N·m (0.7 kgf·m, 5.2 lbf·ft) ALOC bolt; replace with a new one
Front fender mounting bolt 12 N·m (1.2 kgf·m, 9 lbf·ft)
