HYDRAULIC BRAKE
15-7
BRAKE FLUID REPLACEMENT/AIR
BLEEDING (CBF600SA/NA)
Spilled brake fluid will severely damage the plastic
parts and painted surfaces. Place a shop towel over
these parts whenever the system is serviced.
• Do not allow foreign material to enter the system
when filling the reservoir.
• When using a commercially available brake
bleeder, follow the manufacture’s operating
instructions.
BRAKE FLUID DRAINING
Lever Brake Line:
For the front brake, turn the handlebar to the left
until the reservoir is parallel to the ground, before
removing the reservoir cap.
Remove the screws and reservoir cap.
Remove the set plate and diaphragm.
Connect a bleed hose to the left caliper bleed valve.
Loosen the bleed valve and pump the brake lever
until no more fluid flows out of the bleed valve.
Connect a bleed hose to the right caliper bleed
valve.
Loosen the upper bleed valve and pump the brake
lever until no more fluid flows out of the bleed
valve.
RESERVOIR CAP/SET PLATE/DIAPHRAGM
SCREWS
