MAINTENANCE
3-25
REAR BRAKE
Support the motorcycle upright on a level surface.
Remove the right side cover (page 2-5).
Check the fluid level in the rear brake fluid reservoir.
If the level is near the "LOWER" level line, remove
the mounting bolt and the reservoir cap, and fill the
reservoir with DOT 4 brake fluid from a sealed con-
tainer to the "UPPER" level line.
Install the reservoir cap with the diaphragm and set
plate.
Install the reservoir onto the frame and tighten the
mounting bolt.
Install the right side cover (page 2-5).
BRAKE PAD WEAR
FRONT BRAKE PADS
Check the brake pad for wear.
Replace the brake pads if either pad is worn to the
bottom of wear limit groove.
Refer to brake pad replacement:
– CBF600SA/NA (page 15-15)
– CBF600S/N (page 15-16)
REAR BRAKE PADS
Check the brake pad for wear.
Replace the brake pads if either pad is worn to the
bottom of wear limit groove.
Refer to brake pad replacement:
– CBF600SA/NA (page 15-15)
– CBF600S/N (page 15-16)
TORQUE: 10 N·m(1.0kgf·m, 7 lbf·ft)
"LOWER"
"UPPER"
RESERVOIR CAP
BOLT
