ANTI–LOCK BRAKE SYSTEM (ABS; CBF600SA/NA)
16-5
ABS CONNECTOR LOCATIONS
NOTE 1: Lift and support the fuel tank (page 3-5).
NOTE 2: Remove the seat (page 2-4).
FRONT WHEEL SPEED SENSOR 2P
(Blue) CONNECTOR (NOTE 1)
Sensor side:
Main harness side:
ABS SERVICE CHECK CONNECTOR
(NOTE 2)
