ANTI–LOCK BRAKE SYSTEM (ABS; CBF600SA/NA)
16-6
NOTE 3: Remove the right side cover (page 2-5).
ABS MODULATOR 25P CONNECTOR
(NOTE 2)
REAR WHEEL SPEED SENSOR 2P
(Red) CONNECTOR (NOTE3)
Sensor side:
Main harness side:
