Honda CBF600SA - (Cbf600 S;Sa); Front Left;Right Cowl; Windscreen (Cbf600 S;Sa)

FRAME/BODY PANELS/EXHAUST SYSTEM
2-9
FRONT LEFT/RIGHT COWL
(CBF600S/SA)
REMOVAL/INSTALLATION
Remove the two socket bolts (long/short), bolt/collar
and trim clip.
Release the boss from the groove on the upper cowl
and tabs from the grooves on the upper cowl.
Disconnect the turn signal 2P connector.
Installation is in the reverse order or removal.
WINDSCREEN (CBF600S/SA)
REMOVAL
Remove the windscreen covers.
Remove the screws and windscreen.
GROOVE
2P
CONNECTOR
TABS
GROOVES
BOLT/COLLAR
CLIP
BOSS
SOCKET BOLT (LONG)
SOCKET BOLT
(SHORT)
COVERS
SCREWS
WINDSCREEN
