GENERAL INFORMATION
1-15
CYLINDER HEAD/VALVES
CLUTCH/STARTER CLUTCH/GEARSHIFT LINKAGE
ALTERNATOR
ITEM Q'TY
THREAD TORQUE
REMARKS
DIA. (mm) N·m (kgf·m, lbf·ft)
Cylinder head mounting bolt 10 9 47 (4.8, 35) Apply molybdenum oil solu-
tion to the threads and seating
surface.
Camshaft holder flange bolt 20 6 12 (1.2, 9) Apply engine oil to the
threads and seating surface.
Cylinder head cover bolt 4 6 10 (1.0, 7)
PAIR check valve cover bolt 4 6 12 (1.2, 9) CT bolt
Cam sprocket bolt 4 7 20 (2.0, 15) Apply a locking agent to the
threads.
Cam chain tensioner A pivot bolt 1 6 12 (1.2, 9) Apply a locking agent to the
threads.
Cam chain tensioner B pivot bolt 1 10 20 (2.0, 15) Apply a locking agent to the
threads.
Cam chain guide A bolt 1 6 12 (1.2, 9)
Bleeding joint 1 8 12 (1.2, 9) Apply a locking agent to the
threads.
Exhaust pipe stud bolt 8 8 See page 2-11
ITEM Q'TY
THREAD TORQUE
REMARKS
DIA. (mm) N·m (kgf·m, lbf·ft)
Clutch center lock nut 1 22 128 (13.1, 94) Apply engine oil to the
threads and seating surface.
Stake.
Clutch spring bolt 5 6 12 (1.2, 9)
Starter clutch outer mounting bolt 1 10 83 (8.5, 61) Apply engine oil to the
threads and seating surface.
Shift drum center socket bolt 1 8 23 (2.3, 17) Apply a locking agent to the
threads.
Shift drum stopper arm pivot bolt 1 6 12 (1.2, 9) Apply a locking agent to the
threads.
Gearshift spindle return spring pin 1 8 22 (2.2, 16)
ITEM Q'TY
THREAD TORQUE
REMARKS
DIA. (mm) N·m (kgf·m, lbf·ft)
Stator wire clamp flange bolt 1 6 12 (1.2, 9) CT bolt
Flywheel flange bolt 1 10 113 (11.5, 83) Apply engine oil to the
threads and seating surface.
Stator mounting socket bolt 4 6 12 (1.2, 9)
