ENGINEERING CMANUAL OF AUTOMATION CONTROL
AIR HANDLING SYSTEM CONTROL APPLICATIONS
226
SPACE TEMPERATURE CONTROL OF ZONE MIXING DAMPERS AND RESET OF HOT
DECK TEMPERATURE
Functional Description
33
SA
MA
ON
74
46
HOT
DECK
ZONE
MIXING
DAMPERS
AS THE DEMAND FOR HEAT FROM THE ZONE WITH
THE GREATEST DEMAND FOR HEAT VARIES FROM
ZERO TO %, THE HOT DECK TEMPERATURE
SETPOINT SHALL VARY FROM THE MIXED AIR
TEMPERATURE TO DEGREES.
AS THE DEMAND FOR HEAT FROM EACH ZONE VARIES
FROM TO %, ITS HOT DECK
DAMPERS SHALL MODULATE FROM CLOSED TO OPEN.
74
SETPOINT
SPACE
TEMP.
%
OPEN
SETPOINT
HALL
LOBBY
M10461
1
2
7
6
3
8
5
9
74
62
74
74
90
72%
90
83
74
EAST
OFFICE
WEST
OFFICE
10
4
CONTROL
PROGRAM
NORMAL
NO
56
PERCENT
OPEN TO
HOT DECK
80
15
AS THE DEMAND FOR HEAT FROM THE ZONE WITH
THE GREATEST DEMAND FOR HEAT VARIES FROM
TO 100%, THE HOT DECK TEMPERATURE
SETPOINT SHALL VARY FROM TO
DEGREES.
80
105
55
15 55
Item
No. Function
1-2 Control system energizes when fan is turned
on (See FAN SYSTEM START-STOP
CONTROL).
3-4 Zone mixing dampers modulate to maintain
zone temperature setpoint.
5-7 Hot water valve modulates to maintain hot
deck temperature setpoint.
8 MA temperature determines hot deck reset
schedule start point.
9 Dynamic graphic sequence display permits
the operator to adjust program setpoints.
Program adjusts hot deck temperature based
upon operator inputs.
10 Control program coordinates load reset,
temperature, and fan interlock programs.
