Honeywell AUTOMATIC CONTROL User Manual

ENGINEERING CMANUAL OF AUTOMATION CONTROL
AIR HANDLING SYSTEM CONTROL APPLICATIONS
248
YEAR-ROUND SYSTEM CONTROL PROCESSES
HEATING, COOLING, AND ECONOMIZER
Functional Description
M10478
OA
EA
RA
SA
3
2
ON
ON
1
100
5
100
1619
4
20
NORMAL
ECONOMIZER DECISION.
REFER TO PREVIOUS
ECONOMIZER OPTIONS
OA MINIMUM SETPOINT
(NOTE: THE TEST AND BALANCE
INITIAL VALUE FOR PROPER
VENTILATION IS 22)
7
6
22
CONTROL
PROGRAM
22
96
17
14
18
105
55
SUPPLY AIR
TEMPERATURE
SETPOINT
SPACE
HEATING
DEMAND
100
0
75
55
SUPPLY AIR
TEMPERATURE
SETPOINT
CHW
COOLING
DEMAND
0
100
75
57
SUPPLY AIR
TEMPERATURE
SETPOINT
FREE
COOLING
DEMAND
0
100
64
21
036
SUPPLY
FAN
PERCENT
OPEN
NC
NO
NC
SPACE TEMPERATURE
15
59
64
11
9
10
74
76
2.0
8
76
SETPOINT
13
72
SETPOINT
100
0
CHILLED WATER COOLING
SETPOINT = FREE COOLING
SETPOINT PLUS
FREE COOLING
SETPOINT
(1.5 MINIMUM)
12
2.0
HEATING SETPOINT = FREE
COOLING SETPOINT MINUS
(1.5 MINIMUM)
Item
No. Function
1-3 Control system energizes when fan is turned
on (See FAN SYSTEM START-STOP
CONTROL).
4-6 Mixing dampers modulate to maintain
minimum ventilation value and free cooling
SA temperature setpoint.
7 Economizer enables free cooling when OA is
appropriate.
8 Space temperature dictates heat and cool
demands.
9-13 Free cooling setpoint and heat/cool deadband
values determine the SA temperature setpoint
for hot and chilled water control setpoints.
Software has a minimum 1.5 Fahrenheit
degree heating and cooling deadband.
14 Heat demand varies SA temperature setpoint.
15,16 Hot water valve modulates to maintain SA
