3 EC350 installation
3.8 General Wiring connections
Honeywell 2024
45
The "weight" of each pulse (e.g. whether a pulse corresponds to 10 cubic feet or 1 cubic meter) is
configured via items 1193-1195.
Note: In prior Mercury products the pulse weight was configured differently through items 93-95.
These are now read-only values provided for reference.
Pulse output timing is configurable via items 1014, 1015, and 1024. Various pulse ON and OFF times can
be chosen. Default is a pulse ON time of 62.5 milliseconds and a pulse OFF time of at least 62.5
milliseconds, for a minimum pulse period of 125 milliseconds.
Pulse Output Configuration Summary
Channel Item function Item
number
Parameters Description
A Enable/Type 93
0 = CorVol
pulses
2 = UncVol
pulses
3 = Off
Channel A pulse output selection.
Select the type of information to be
transmitted out of Channel A.
Weight 1193 100 CF
(Default)
Volume associated with a single pulse
on channel A.
Timing 1014 50/250 ms Channel A pulse output timing. Select
the On and Off timing requirements for
Channel A output.
Queue 5 0 (Default) Channel A pulses waiting. Provides the
number of pulses waiting to be sent to
the remote device.
Pulse queue = 2 x the number of
Channel A output pulse remaining
from the previous wakeup period.
