Channel Item function Item
number
Parameters Description
B Enable/Type 94
0 = CorVol
pulses
2 = UncVol
pulses
3 = Off
Channel B pulse output selection.
Select the type of information to be
transmitted out of Channel B.
Weight 1194 100 CF
(Default)
Volume associated with a single pulse
on channel B.
Timing 1015 50/250 ms Channel B pulse output timing. Select
the On and Off timing requirements for
Channel B output.
Queue 6 0 (Default)
Channel B pulses waiting. Provides the
number of pulses waiting to be sent to
the remote device.
Pulse queue = 2 x the number of
Channel B output pulse remaining
from the previous wakeup period.
