10 IFP-75/IFP-75HV Installation/Operation Manual — P/N LS10147-001SK-E:D 06/25/2021
Introduction About this Manual
1.2 About this Manual
1.2.1 Terms Used in this Manual
The following terminology is used with the IFP-75 System:
1.3 Compatible Products
The chart below lists the products available for use with the IFP-75.
Term Description
SLC Signaling Line Circuit
Module The term module is used for all hardware devices except for SLC addressable devices and notification
appliances. This includes the IFP-75 panel itself.
Input Point An addressable sensing device, such as a smoke or heat detector or a contact monitor device.
Input Zone A protected area made up of input points.
Output Point (or Output Circuit) A notification point or circuit used for notification appliances. Relay circuits and auxiliary power circuits are
also considered output points.
Group (or “Output Group”) A group of output points. Operating characteristics are common to all output points in the group.
Output (or “Cadence”) Pattern The pattern that the output will use, for example, Constant, March Code, ANSI 3.41. Applies to zones and
special system events. See Appendix D for additional information.
Mapping Mapping is the process of specifying which outputs are activated when certain events occur in the System.
Section 8, Figure 8.2 explains mapping in detail.
Network System Consist of any combination of 32 panels of these model numbers: IFP-75, IFP-300, IFP-300ECS, IFP-2100
or IFP-2100,ECS, IFP-75.
SWIFT Smart Wireless Integrated Fire Technology
Table 1.1 Manual Terminology
Type of Device Model Description
IDP Addressable SLC Devices
For information on the compatible Addressable SLC Devices, refer Chapter 7.
SWIFT Wireless SLC Devices For information on the compatible SWIFT Devices, refer to the SWIFT manual #LS10036-000FH-E.
Other Modules Wireless 5824 Serial/Parallel Printer
Interface Module
Allows a printer to be attached for the on-site event logging. Maximum of four
5824 modules per control panel.
RPS-1000 Power Supply Provides additional power, six Flexput circuits, and two Form C relays. Max 8 per
System. See RPS-1000 Installation Manual (PN 151153) for more information.
5496 NAC Expander Provides 4 additional Notification Appliance Circuits/Auxiliary power.
(Up to 8 per IFP-75 System.)
RA-100 and RA-100R LCD
Annunciator
4 x20 Remote LCD annunciator. can be used in any combination, up to a total of 8
devices on one panel.
RA-1000 and RA-1000R
LCD Annunciator
4 x20 Remote LCD annunciator can be used in any combination, up to a total of 8
devices on one panel.
RA-2000 LCD Annunciator 4 x 40 Remote LCD annunciator can be used in any combination, up to a total
of 8 devices on one panel.
5865-3 and 5865-4 LED
Annunciator
LED annunciator can display up to 30 LEDs (15 red and 15 yellow). 5865-4 has
key switches for silence and reset, and a system trouble LED. 5865-3, 5865-4, and
5880 can be used in any combination, up to a total of eight devices on one panel.
RA-100TG and RA-100TR
Trim Ring
Trim ring kits for surface mounting the RA-100/RA-100R annunciator. RA-100TG is
gray; RA-100TR is red.
5860TG and
5860TR Trim Rings
Trim ring kits for surface mounting theRA-1000 annunciator. 5860TG is gray;
5860TR is red.
5880 LED Driver Module Driver for up to 40 LEDs. Interfaces with customized annunciator boards. In
addition the 5880 has eight generic switch input points.
5883 General Purpose
Relay Module
Provides 10 Form C relays. Designed to be driven by the 5880. Up to four,
5883 relays can be used with each 5880 module.
SK-NIC Network Interface Card
SK-FML Fiber-Optic Multi Mode
SK-FSL Fiber-Optic Single Mode
Wireless IDP-WGI Wireless Gateway
IDP-PHOTO Wireless Photoelectric Smoke Detector with 4" base
WIDP-ACCLIMATE Wireless Multi criteria photoelectric smoke detector with thermal (135°F) with 4"
base
WIDP-HEAT-ROR Wireless ROR Heat Detector heat, ROR/ 135° fixed with 4" base
WIDP-HEAT Wireless Heat, 135° Fixed Heat Detector with 4" base
WIDP-MONITOR Wireless Addressable Monitor module
Table 1.2 IFP-75 Compatible Products
