106 IFP-75/IFP-75HV Installation/Operation Manual — P/N LS10147-001SK-E:D 06/25/2021
System Operation Menu System
10.3 Menu System
The Control Panel is easy to operate from the Main Menu. To view the Main Menu, press ENTER or press the right arrow key
on the control panel or the remote annunciator. The Main Menu will appear as shown in Section 10.3.1. Select the desired
option and enter your Access Code if prompted. The Control Panel supports up to 20 Access Codes. The profile for each
Access Code (or user) can be modified through the Programming Menu option (see Section 6.2.5 for Access Code program-
ming).
10.3.1 Main Menu Overview
Table 10.1 lists a brief overview of the Main Menu. These options are described in greater detail throughout this section of the
manual.
10.3.2 Using the Menus
10.4 Basic Operation
10.4.1 Setting the Time and Date
1. Select 4 to access the Set Date & Time.
2. Make changes in the fields on the screen. Use the right arrow key to move the cursor through the fields. Use the up or
down arrow key to select options in the fields.
3. When the date and time are correct, press ENTER.
10.4.2 Disable / Enable a Point
1. Select 2 for Point Functions.
2. Select 1 for Disable/Enable Point.
Disable / Enable NACs by Template
1. Press 1 for Disable NACs by Template, press 2 to Enable NACs by Template.
2. Use the up or down arrow key to move the cursor through the list of templates. Press ENTER to select the current
template.
Disable / Enable NACs by Group
1. Press 3 to Disable NACs by Group, or press 4 to Enable NACs by Group.
2. Use the up or down arrow key to move the cursor through the list of groups. Press ENTER to select the group highlighted.
Disable / Enable Zone Points
1. Press 5 to Disable Zone Points, or press 6 to Enable Zone Points.
2. Use the up or down arrow key to move the cursor through the list of zones. Press ENTER to select the zone highlighted.
Disable / Enable Point
1. Press 7 to Disable /Enable Point.
2. Choose the Module.
3. Use the up or down arrow key to choose Point and press ENTER.
4. Press the right arrow key to disable or enable Point.
Main Menu Options Description
1- System Tests Access to Fire Drill, Indicator Test, Walk Tests, Communicator Test, Clear History Buffer, Manual
AlarmNet Registration and Manual Communicator Reset.
2- Point Functions From here you can enable / disable points.
3- Event History Display event history on the LCD. See Section 10.4.4 for more information.
4- Set Time and Date Set time and date for the System.
5- Network Diagnostics Ping Panel and Data Network Status
6- Network Programming Access Learn Network, Edit Network Names, Edit Panel ID, Computer Access, Access Codes,
Communicator Options, Sync Network Options.
7- Panel Programming Brings up a set of Menus for programming the panel. These options are described in detail in
Section 8.
8- System Information Menus to view information about the panel such as model, ID, serial number, revision, send or
receive firmware updates and feature registration activation.
Table 10.1 Main Menu Options
To move through the Menus: Use up and down arrows to move through the options in a Menu. Use the left arrow to move to a
previous Menu.
To select an option: Enter the number of the option, OR press ENTER if the option appears at the top of the Menu
(= symbol displays after the option number in this case).
Table 10.2 Using the Menus
