IFP-75/IFP-75HV Installation/Operation Manual — P/N LS10147-001SK-E:D 06/25/2021 15
Section 3: Prerequisites for Installation
This Section of the manual is intended to help you plan your tasks to facilitate a smooth installation. Please read this section thoroughly,
especially if you install the IFP-75 panel for the first time.
3.1 Inventory
When the IFP-75 shipment is received, check that all the parts have been included in the shipment. The shipment consists of one of each of
the following:
• main circuit board with the display
• backbox with door
• plastic bag containing two keys, screws, cables, and ten 4.7K ohm end-of-line resistors
• manual
3.2 Environmental Specifications
It is important to protect the IFP-75 control panel from water. To prevent water damage, the following precautions should be followed when
you install the units:
• Intended for indoor use in dry locations only.
• Do not mount the panel directly on exterior walls, especially masonry walls (condensation).
• Do not mount the panel directly on exterior walls below grade (condensation).
• Protect the panel from plumbing leaks.
• Protect the panel from splash caused by Sprinkler System inspection ports.
• Do not mount the panel in areas with humidity-generating equipment (such as dryers, production machinery).
When you select a location to mount the IFP-75 control panel, the unit should be mounted where it will NOT be exposed to temperatures out-
side the range of 0°C-49°C (32°F-120°F) or humidity outside the range of 10%-93% at 30°C (86°F) non-condensing.
3.3 Software Downloads
In order to supply the latest features and functionality in fire alarm and life safety technology to our customers, we make frequent upgrades
to the embedded software in our products. To ensure that you install and program the latest features, we strongly recommend that you down-
load the most current version of software for each product prior to commissioning any System. Contact Technical Support with any ques-
tions about software and the appropriate version for a specific application. The HFSS Honeywell Fire Software Suite is available at
www.farenhyt.com.
3.4 Electrical Specifications
Table 3.1 lists the terminal block on the IFP-75 as well as a description of each individual terminal and their respective electrical rating. For
information on the location of the terminals, refer to Figure 3.2. See also Section 4 for the installation information.
Terminal No.
Label
Description
Rating
Group Individual Voltage Current
Terminal Block 3 TELCO 1 RING Phone Line 1 Telco Ring
TIP Phone Line 1 Telco Tip
PHONE 1 RING Phone Line 1 Phone Ring
TIP Phone Line 1 Phone Tip
TELCO 2 RING Phone Line 2 Telco Ring
TIP Phone Line 2 Telco Tip
PHONE 2 RING Phone Line 2 Phone Ring
TIP Phone Line 2 Phone Tip
Terminal Block 2 RELAY 1 NO Normally open relay contact 27.4 VDC 2.5 A, resistive
COM Common terminal
NC Normally closed relay contact
RELAY 2 NO Normally open relay contact 27.4 VDC 2.5 A, resistive
COM Common terminal
NC Normally closed relay contact
TROUBLE NO Normally open relay contact 27.4 VDC 2.5 A, resistive
COM Common terminal
NC Normally closed relay contact
SLC IN – Used for Class A installations 32 VDC 100 mA
+
SLC OUT
–
SLC terminals 32 VDC 100 mA
+
SLC PROG – Used for programming SLC Detectors 32 VDC 100 mA
+
Table 3.1 Terminal Descriptions and Electrical Specifications
