16 IFP-75/IFP-75HV Installation/Operation Manual — P/N LS10147-001SK-E:D 06/25/2021
Prerequisites for Installation Electrical Specifications
Terminal Block 2
SBUS – SBUS Power 27.4 VDC 0.5 A
+
A SBUS Communication 5 VDC 100 mA
B
NAC1* – Notification Appliance Circuit/Auxiliary
power
27.4 VDC 1 Amp NAC or Aux power
+
NAC2* – Notification Appliance Circuit/Auxiliary
power
27.4 VDC 1 Amp NAC or Aux power
+
P8 EXT. Comm
Cellular
Connection
B Cellular Transmitter input
A
S+ 55 mA, 95 mA
S-
P7 Data Network Used for SK-NIC 24 VDC 21 mA
Note: *Regulated NAC application. When programmed for releasing, NAC are Special Application.
Terminal No.
Label
Description
Rating
Group Individual Voltage Current
Table 3.1 Terminal Descriptions and Electrical Specifications (Continued)
To Next Page
