66 IFP-75/IFP-75HV Installation/Operation Manual — P/N LS10147-001SK-E:D 06/25/2021
Section 7: IDP, SK, SD and SWIFT
SLC Device Installation
7.1 List of IDP SLC Devices
Table 7.1 lists the following IDP SLC devices that can be used with the control panel. For additional information, refer to the Product Instal-
lation Instructions (packaged with the device).
CAUTION: DISCONNECT POWER
TO AVOID THE RISK OF ELECTRICAL SHOCK AND DAMAGE TO THE UNIT, POWER SHOULD BE OFF AT THE
CONTROL PANEL WHILE INSTALLING OR SERVICING.
NOTE: The control panel supports the use of the IDP, SK, or SD SLC devices. You cannot install a mixture or combination of SLC device types
on the control panel. The IDP, SK, or SD SLC devices can be used with the IDPSK wireless devices.
Part Number Model Name/Description Install Sheet PN
OSI-RI-FH Intelligent imaging beam smoke detector including reflector I56-6585
IDP-PTIR-W Multi-criteria photo electric thermal and infrared smoke detector I56-6619
IDP-PHOTO Photoelectric smoke detector I56-4279I56-6521
IDP-PHOTO-T Photoelectric smoke detector with thermal (135°F)
PHOTO-R Intelligent Photoelectric smoke sensor
IDP-PHOTO-R Photoelectric replacement smoke detector with remote test capability in DNR I56-6520
IDP--ACCLIMATE Multi criteria photoelectric smoke detector with thermal (135°F) I56-3611
IDP-BEAM Reflected beam smoke detector without test feature
I56-2735
IDP-BEAM-T Reflected beam smoke detector with test feature
DNR/DNRW Duct smoke detector housing. Non-relay (PhotoR or Photo sold separate) I56-3051
IDP-HEAT Fixed temperature thermal detector (135°F) I56-2722
I56-6974
IDP-HEAT-ROR Rate-of-rise thermal detector with 135° fixed temperature
IDP-HEAT-HT Fixed high temperature thermal detector (190°F)
IDP-PULL-SA Addressable single action pull station I56-2736
IDP-PULL-DA Addressable dual action pull station I56-3605
IDP-ISO Fault isolator module I56-2729
IDP-MONITOR Monitor module I56-3442
IDP-MINIMON Mini monitor module I56-3444
IDP-MONITOR-2 Dual input monitor module I56-3435
IDP-MONITOR-10 10 input monitor module I56-3443
IDP-RELAY Addressable relay module I56-3601
IDP-RELAY-6 Six relay control module I56-3439
IDPIDP-RELAYMON-2 Dual relay/monitor module I56-3734
IDP-ZONE Addressable zone interface module I56-3602
IDP-ZONE-6 Six zone interface module I56-3441
IDP-CONTROL Supervised control module I56-3436,
IDP-CONTROL-6 Six circuit supervised control module I56-3437,
IDP-FIRE-CO CO Smoke Detector I56-3946
B210LP 6" mounting base I56-0595
B224BI-WH / IV 6" isolator base. White or Ivory I56-3736
B224RB-WH / IV 6" relay base. white or Ivory I56-3737
B200SR-WH / IV 6" temporal sounder base. White or Ivory I56-3392
B200S-WH / IV Intelligent Sounder Base. White or Ivory I56-3887
B501 4" mounting base I56-3738
B501-WHITE / IV / BL 4" mounting base I56-3738
B200SR-LF-WH/ IV Low Frequency Sounder Base. white or Ivory I56-4152
B200S-LF-WH / IV Low Frequency Sounder Base. White or Ivory I56-4151
IDP-PHOTO-W / IV Photoelectric smoke detector. White or Ivory I56-6531
IDP-PHOTO-R-W/ IV Photoelectric replacement smoke detector with remote test capability in DNR. White
or Ivory
I56-6532
IDP-PHOTO-T-W/ IV Photoelectric smoke detector with thermal (135°F) White or Ivory I56-6534
IDP-HEAT-W/ IV
Fixed temperature thermal detector (135°F). White or Ivory I56-6533
IDP-HEAT-ROR-W / IV Rate-of-rise thermal detector with 135° fixed temperature. White or Ivory I56-6533
IDP-HEAT-HT-W / IV
Fixed high temperature thermal detector (190°F). White or Ivory I56-6533
Color Guide: -IV = Ivory color, -BL = Black, -WH = White, -WHITE-White
Table 7.1 IDP SLC Devices
