IFP-75/IFP-75HV Installation/Operation Manual — P/N LS10147-001SK-E:D 06/25/2021 125
SIA / IFP-75 Panels PI Modifier Reporting: Reporting
11.2 SIA / IFP-75 Panels PI Modifier Reporting:
Events are sent to the Central Station as a variable length string:
The Event Format is:
EEZZZZ
Where the Event Format is defined as follows:
1. The Account Number is sent using an Account block that is separate from the Event block.
2. Multiple events can be sent within a single Event block. Events are separated by a “/” character.
3. The Event parameter can be a zone, point or module number.
4. When Reporting-by-Point is enabled, the communicator uses a “pi” event to supersede the actual point event to report the module to
which the point is linked.
5. The Panel ID is not sent in the SIA Event Parameters.
For Example see Table 11.3:
System-based Wireless Gateway
Trouble - restore
pi Exp. ID UJ Point # UJNNXXPPPP 3 373 Exp. ID Point #
Wireless Gateway Trouble pi Exp. ID UT Point # UTNNXXPPPP 1 373 Exp. ID Point #
Wireless Gateway Trouble restore pi Exp. ID UJ Point # UJNNXXPPPP 3 373 Exp. ID Point #
SIA Reporting Format
Contact ID Reporting Format
SIA pi Modifier SIA
Event Description Module ID
# (If Any)
SIA
Event
Codes
Parameter Fixed Length
Format NN - panel
ID
XX- SBUS ID
ZZZ- Zone #
PPPP- Point #
GGG- Group #
E- Emergency #
RRRR-Receiver #
Qualifier Event
Code
Group # Contact #
Table 11.2 Reporting Formats Table (Continued)
Code Event Code Description
EE
Event Code (2 characters)
ZZZZ Event parameter (up to four digits – not zero filled)
Event Report Zone/ Point Panel ID Module Zone ZZZZ Point ZZZZ Fields Sent SIA Event Data
Fire Alarm-Zone Zone n/a n/a97 15 n/a EE-ZZ FA15
Fire Alarm-Zone Zone n/a n/a 05 n/a EE-Z FA5
Fire Alarm-Point Point n/a 01 n/a 123 EE-ZZ /EE-ZZZ pi01/FA123
Fire Alarm-Point Point n/a 33 n/a 203 EE-ZZ /EE-ZZZ pi11/FA203
Expander Trouble n/a n/a 11 n/a n/a EE-ZZ ET11
Auto Test n/a n/a n/a n/a n/a EE-Z RP0
Battery Trouble-Panel 32 n/a n/a 98 n/a n/a EE-ZZ YT98
Battery Trouble-Expander 18 n/a n/a 18 n/a n/a EE-ZZ YT18
SLC Loop Shorted n/a n/a 44 n/a n/a EE-ZZ ET44
Program Begin Panel ID=32 n/a n/a n/a n/a n/a EE-Z LB0
Program Begin Panel ID= 22 n/a n/a n/a n/a n/a EE-Z LB0
AC Power Loss - Panel 22 n/a n/a 98 n/a n/a EE-Z AT0
Fire Trouble Point n/a 97 n/a 200 EE-ZZ /EE-ZZZ pi97/FT200
Fire Trouble Zone n/a 97 01 n/a EE-Z FT1
Fire Trouble-Nac Point n/a 98 n/a Nac Circuit
7
EE-ZZ /EE-Z pi98/FT7
Z=Pt. #
Fire Trouble-Nac Zone n/a 98 n/a Nac Circuit
7
EE-ZZZ FT400
ZZZ=OPG#
Table 11.3 :SIA- IFP-75 Panels - PI Modifier Reporting Examples
