Zone-based AUX1 switch trouble UT Zone # + 1000 UTNN001ZZZ 1 373 01 Zone #
Zone-based AUX1 switch trouble restore UJ Zone # + 1000 UJNN001ZZZ 3 373 01 Zone #
Zone-based AUX2 switch alarm UA Zone # + 2000 UANN002ZZZ 1 140 02 Zone #
Zone-based AUX2 switch alarm restore UH Zone # + 2000 UHNN002ZZZ 3 140 02 Zone #
Zone-based AUX2 switch trouble UT Zone # + 2000 UTNN002ZZZ 1 373 02 Zone #
Zone-based AUX2 switch trouble restore UJ Zone # + 2000 UJNN002ZZZ 3 373 02 Zone #
Point Events: For devices, sensors 1–99 are reported as Points 1–99, modules 1–99 are reported as Points 201–299.
.
An unexpected SLC device has been de-
tected
pi Exp. ID XE Point # XENNXXPPPP 1 380 Exp. ID Point #
An unexpected SLC device has been re-
moved
pi Exp. ID XI Point # XINNXXPPPP 3 380 Exp. ID Point #
Auxiliary power disabled pi Exp. ID FB Point # FBNNXXPPPP 1 571 Exp. ID Point #
Auxiliary power enabled pi Exp. ID FU Point # FUNNXXPPPP 3 571 Exp. ID Point #
Auxiliary power Trouble pi Exp. ID FT Point # FTNNXXPPPP 1 320 Exp. ID Point #
Auxiliary power trouble restore pi Exp. ID FJ Point # FJNNXXPPPP 3 320 Exp. ID Point #
Background Music Switch is Trouble pi Exp. ID UT Point # UTNNXXPPPP 1 379 Exp. ID Point #
Background Music Switch is Trouble Re-
stored
pi Exp. ID UJ Point # UJNNXXPPPP 3 379 Exp. ID Point #
Background Music Switch is Disabled pi Exp. ID UB Point # UBNNXXPPPP 1 580 Exp. ID Point #
Background Music Switch is Enabled pi Exp. ID UU Point # UUNNXXPPPP 3 580 Exp. ID Point #
CO Detector Trouble pi Exp. ID GT Point # GTNNXXPPPP 1 373 Exp. ID Point #
CO Detector Trouble Restore pi Exp. ID GJ Point # GJNNXXPPPP 3 373 Exp. ID Point #
CO Detector Disabled pi Exp. ID GB Point # GBNNXXPPPP 1 571 Exp. ID Point #
CO Detector Enabled pi Exp. ID GU Point # GUNNXXPPPP 3 571 Exp. ID Point #
Detector Alarm pi Exp. ID FA Point # FANNXXPPPP 1 110 Exp. ID Point #
Detector Alarm restore pi Exp. ID FH Point # FHNNXXPPPP 3 110 Exp. ID Point #
Detector Disabled pi Exp. ID FB Point # FBNNXXPPPP 1 571 Exp. ID Point #
Detector Enabled pi Exp. ID FU Point # FUNNXXPPPP 3 571 Exp. ID Point #
Detector Trouble pi Exp. ID FT Point # FTNNXXPPPP 1 373 Exp. ID Point #
Detector Trouble restore pi Exp. ID FJ Point # FJNNXXPPPP 3 373 Exp. ID Point #
Detector CO Alarm pi Exp. ID GA Point # GANNXXPPPP 1 162 Exp. ID Point #
Detector CO Alarm Restore pi Exp. ID GH Point # GHNNXXPPPP 3 162 Exp. ID Point #
Detector CO Supervisory Alarm pi Exp. ID GS Point # GSNNXXPPPP 1 200 Exp. ID Point #
Detector CO Supervisory Alarm Restore pi Exp. ID GR Point # GRNNXXPPPP 3 200 Exp. ID Point #
ECS Alarm # Point Alarm pi Exp. ID QA (EPPP)
E - Emergency #
PPP - Point #
QANNXXEPPP 1 220 +
Emer-
gency #
Exp. ID Point #
ECS Alarm # Point Alarm Restore pi Exp. ID QH (EPPP)
E - Emergency #
PPP - Point #
QHNNXXEPPP 3 220 +
Emer-
gency #
Exp. ID Point #
ECS Alarm # Point Trouble pi Exp. ID QT Point # QTNNXXPPPP 1 242 Exp. ID Point #
ECS Alarm # Point Trouble Restore pi Exp. ID QJ Point # QJNNXXPPPP 3 242 Exp. ID Point #
ECS Alarm # Point Disabled pi Exp. ID QB Point # QBNNXXPPPP 1 243 Exp. ID Point #
ECS Alarm # Point Enabled pi Exp. ID QU Point # QUNNXXPPPP 3 243 Exp. ID Point #
ECS Supervisory/Tamper Alarm pi Exp. ID QS Point # QSNNXXPPPP 1 241 Exp. ID Point #
SIA Reporting Format
Contact ID Reporting Format
SIA pi Modifier SIA
Event Description Module ID
# (If Any)
SIA
Event
Codes
Parameter Fixed Length
Format NN - panel
ID
XX- SBUS ID
ZZZ- Zone #
PPPP- Point #
GGG- Group #
E- Emergency #
RRRR-Receiver #
Qualifier Event
Code
Group # Contact #
Table 11.2 Reporting Formats Table (Continued)
