194 HH490 User Guide
Parameter (Continued) Specification
Mechanical Drop Withstands 1.2m drops (2 times)
ESD Tolerance Up to 15kV direct air
Up to 8 kV indirect coupling plane
Sealant Rating IP40
Image Size 1280 x 800 pixels
Scan Performance
Skew Angle +65°
Pitch Angle +60°
Motion Tolerance Up to 75 cm/s for 13 mil UPC at optimal focus
Symbol Contrast 25% or greater (Grade A)
Scan Angle Horizontal: 48°; Vertical: 30°
Depth of Field Charts
Typical Performance
Symbology Near Distance/mm Far Distance/mm
5 mil Code 39 40 225
6.7mil PDF417 50 210
10mil Data Matrix 45 185
13mil UPC-A 35 430
20mil QR Code 20 355
Resolution (Code 39) 3mil
Resolution (PDF 417) 4mi
Resolution (QR) 6mil
Resolution (DM) 5mil
