Honeywell HH490 User Manual

HH490 User Guide 201
APPENDIX A - REFERENCE CHARTS
Symbology Charts
Note: “m” represents the AIM modifier character. Refer to International Technical
Specification, Symbology Identifiers, for AIM modifier character details.
Prefix/Suffix entries for specific symbologies override the universal (All
Symbologies, 99) entry.
Refer to Data Edit beginning on page 53 and Data Format beginning on page 59
for information about using Code ID and AIM ID.
Linear Symbologies
AIM Honeywell
Linear Symbology ID Possible modifiers (m) ID Hex
All Symbologies 99
Codabar ]F m 0-1 a 61
Code 11 ]H3 h 68
Code 128 ]C m 0, 1, 2, 4 j 6A
Code 32 Pharmaceutical (PARAF) ]X0 < 3C
Code 39 (supports Full ASCII mode) ]A m 0, 1, 3, 4, 5, 7 b 62
TCIF Linked Code 39 (TLC39) ]L2 T 54
Code 93 and 93i ]G m 0-9, A-Z, a-m i 69
EAN ]E m 0, 1, 3, 4 d 64
EAN-13 (including Bookland EAN) ]E0 d 64
EAN-13 with Add-On ]E3 d 64
EAN-13 with Extended Coupon Code ]E3 d 64
EAN-8 ]E4 D 44
APPENDIX
A

Honeywell HH490 Specifications

General

Duplex scanning	No
Maximum scan size	- mm
Optical scanning resolution	1280 x 800 DPI
Scanner type	Handheld scanner
Product color	White
Quantity per pack	1 pc(s)
Sensor type	-
Barcode reader	Yes
Daily duty cycle (max)	- pages
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Power supply type	DC
Optional connectivity	Serial (RS-232)

Weight and Dimensions

Depth	72.5 mm
Width	125 mm
Height	154 mm
Weight	130 g
