CHAPTER
5
Thor VM3 with Microsoft Windows Embedded Compact 7 User Guide 133
SOFTWARE
Introduction
There are several different aspects to the setup, configuration and operation of the Thor
VM3. Many of the setup and configuration settings are dependent upon the optional
features such as hardware and software installed on the unit. The examples found in
this section are to be used as examples only, the configuration of your specific Thor
VM3 computer may vary. The following sections provide a general reference for the con-
figuration of the Thor VM3 and some of its optional features.
Operating System
Your Thor VM3 operating system is Microsoft
®
Windows
®
Embedded Compact 7. The
Thor VM3 operating system revision is displayed on the Desktop. This is the default set-
ting for the Desktop Display Background.
Windows Embedded Compact Operating System
This segment assumes the system administrator is familiar with Microsoft Windows
options and capabilities loaded on most standard Windows computers.
Therefore, the sections that follow describe only those Windows capabilities that are
unique to the Thor VM3 and its Windows environment.
General Windows Embedded Compact Keyboard Shortcuts
Use the keyboard shortcuts in the chart below to navigate with the Thor VM3 keyboard.
These are standard keyboard shortcuts for Windows Embedded Compact applications.
Press these keys … To …
CTRL + C Copy
CTRL + X Cut
CTRL + V Paste
CTRL + Z Undo

Honeywell Thor VM3 Specifications

General

Stepping	D0
Tjunction	-40 °C
FSB Parity	No
Processor code	SR1X8
Processor cache	1 MB
Processor cores	2
Processor model	E3826
System bus rate	- GT/s
Processor family	Intel Atom®
Processor codename	Bay Trail
Processor frequency	1.46 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor package size	25 x 27 mm
Conflict-Free processor	Yes
Processor front side bus	- MHz
Processor operating modes	32-bit, 64-bit
Graphics & IMC lithography	22 nm
PCI Express configurations	1x1, 1x4, 2x1
Thermal Design Power (TDP)	7 W
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
Storage media	Flash
Compatible memory cards	-
Internal storage capacity	64 GB
Display diagonal	12.1 \
Display brightness	900 cd/m²
Display resolution	1024 x 768 pixels
Graphics card	HD Graphics
Rear camera resolution (numeric)	- MP
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.0+EDR
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
HDMI ports quantity	0
USB 2.0 ports quantity	1
I/O ports	1x CAN-bus, RF
Processor ARK ID	78477
Processor socket	BGA 1170
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Platform	Windows
Bundled software	Data Collection Engine, Microsoft Internet Explorer, Microsoft on-screen keyboard, Configuration Cloning Utility, Screen Blanking, Zoom Zone, Launcher
Operating system installed	Windows 7
AC adapter input voltage	90 - 240 V
Battery capacity	- mAh
Battery life (max)	0.5 h
Certification	EN 55024:2010, MIL-STD-810F, SAE-J1455, CCX
Device type	Tablet PC
Form factor	Slate
Product color	Grey, Silver
Protection features	Shock resistant, Vibration proof, Water resistant
International Protection (IP) code	IP66
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	62 mm
Width	318 mm
Height	260 mm
Weight	3000 g
