138 Thor VM3 with Microsoft Windows Embedded Compact 7 User Guide
dialog from appearing. Once the drivers are loaded, the slot can be turned on. The
value in the PCMCIA field is a DWORD, representing the number of seconds to wait
after installing the CAB file, but before activating the slot (a latency to allow the
thread loading the driver to finish installation). The default value of 0 means the slot
is not powered on. The default values for the default radio drivers (listed below) is 1,
meaning one second elapses between the CAB file loading and the slot powering up.
The auto-launch process proceeds as follows:
1. The launch utility opens the registry database and reads the list of CAB files to auto-
launch.
2. First it looks for FileName to see if the CAB file is present. If not, the registry entry is
ignored. If it is present, and the Installed flag is not set, auto-launch makes a copy of
the CAB file (since it gets deleted by installation), and runs the Microsoft utility
WCELOAD to install it.
3. If the Installed flag is set, auto-launch looks for the FileCheck file. If it is present, the
CAB file is installed, and that registry entry is complete. If the FileCheck file is not
present, memory has been lost, and the utility calls WCELOAD to reinstall the CAB
file.
4. Then, the whole process repeats for the next entry in the registry, until all registry
entries are analyzed.
5. To force execution every time (for example, for AUTOEXEC.BAT), use a FileCheck of
“dummy”, which will never be found, forcing the item to execute.
6. For persist keys specifying .EXE or .BAT files, the executing process is started, and
then Launch will continue, leaving the loading process to run independently. For
other persist keys (including .CAB files), Launch will wait for the loading process to
complete before continuing. This is important, for example, to ensure that a .CAB file
is installed before the .EXE files from the .CAB file are run.
7. Note that the auto-launch process can also launch batch files (*.BAT), executable
files (*.EXE), registry setting files (*.REG), or sound files (*.WAV). The mechanism is
the same as listed above, but the appropriate application is called, depending on file
type.
Note: Registry entries may vary depending on software revision level and options ordered with
the Thor VM3.
LAUNCH.EXE and Persistent Storage
If any of the following directories are created in the System folder, Launch automatically
copies all of the files in these directories:
System\Desktop copied to Windows\Desktop
System\Favorites copied to Windows\Favorites
System\Fonts copied to Windows\Fonts
System\Help copied to Windows\Help
System\Programs copied to Windows\Programs
AppMgr copied to Windows\AppMgr

Honeywell Thor VM3 Specifications

General

Stepping	D0
Tjunction	-40 °C
FSB Parity	No
Processor code	SR1X8
Processor cache	1 MB
Processor cores	2
Processor model	E3826
System bus rate	- GT/s
Processor family	Intel Atom®
Processor codename	Bay Trail
Processor frequency	1.46 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor package size	25 x 27 mm
Conflict-Free processor	Yes
Processor front side bus	- MHz
Processor operating modes	32-bit, 64-bit
Graphics & IMC lithography	22 nm
PCI Express configurations	1x1, 1x4, 2x1
Thermal Design Power (TDP)	7 W
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
Storage media	Flash
Compatible memory cards	-
Internal storage capacity	64 GB
Display diagonal	12.1 \
Display brightness	900 cd/m²
Display resolution	1024 x 768 pixels
Graphics card	HD Graphics
Rear camera resolution (numeric)	- MP
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.0+EDR
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
HDMI ports quantity	0
USB 2.0 ports quantity	1
I/O ports	1x CAN-bus, RF
Processor ARK ID	78477
Processor socket	BGA 1170
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Platform	Windows
Bundled software	Data Collection Engine, Microsoft Internet Explorer, Microsoft on-screen keyboard, Configuration Cloning Utility, Screen Blanking, Zoom Zone, Launcher
Operating system installed	Windows 7
AC adapter input voltage	90 - 240 V
Battery capacity	- mAh
Battery life (max)	0.5 h
Certification	EN 55024:2010, MIL-STD-810F, SAE-J1455, CCX
Device type	Tablet PC
Form factor	Slate
Product color	Grey, Silver
Protection features	Shock resistant, Vibration proof, Water resistant
International Protection (IP) code	IP66
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	62 mm
Width	318 mm
Height	260 mm
Weight	3000 g
