Honeywell Thor VM3 User Manual

144 Thor VM3 with Microsoft Windows Embedded Compact 7 User Guide
There are a few changes in the Windows Embedded Compact version of Windows
Explorer as it relates to the general desktop PC Windows Explorer options. Tap the “?”
button to access Windows Explorer Help.
Taskbar
Start > Settings > Taskbar
There are a few changes in the Windows Embedded Compact version of Taskbar as it
relates to the general desktop PC Windows Taskbar options.
When the taskbar is auto hidden, press the Ctrl key then the Esc key to make the Start
button appear.
Clicking the Taskbar option on the Settings menu displays the General and Advanced
Taskbar tabs.
General
Factory Default Settings
Advanced
Expand Control Panel
Tap the checkbox to have the Control Panel folders appear in drop down menu format
from the Settings > Control Panel menu option.
Clear Contents of Document Folder
Tap the ton to remove the contents of the Document folder.
Always on Top Enabled
Auto hide Disabled
Show Clock Enabled

Honeywell Thor VM3 Specifications

General

Stepping	D0
Tjunction	-40 °C
FSB Parity	No
Processor code	SR1X8
Processor cache	1 MB
Processor cores	2
Processor model	E3826
System bus rate	- GT/s
Processor family	Intel Atom®
Processor codename	Bay Trail
Processor frequency	1.46 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor package size	25 x 27 mm
Conflict-Free processor	Yes
Processor front side bus	- MHz
Processor operating modes	32-bit, 64-bit
Graphics & IMC lithography	22 nm
PCI Express configurations	1x1, 1x4, 2x1
Thermal Design Power (TDP)	7 W
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
Storage media	Flash
Compatible memory cards	-
Internal storage capacity	64 GB
Display diagonal	12.1 \
Display brightness	900 cd/m²
Display resolution	1024 x 768 pixels
Graphics card	HD Graphics
Rear camera resolution (numeric)	- MP
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.0+EDR
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
HDMI ports quantity	0
USB 2.0 ports quantity	1
I/O ports	1x CAN-bus, RF
Processor ARK ID	78477
Processor socket	BGA 1170
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Platform	Windows
Bundled software	Data Collection Engine, Microsoft Internet Explorer, Microsoft on-screen keyboard, Configuration Cloning Utility, Screen Blanking, Zoom Zone, Launcher
Operating system installed	Windows 7
AC adapter input voltage	90 - 240 V
Battery capacity	- mAh
Battery life (max)	0.5 h
Certification	EN 55024:2010, MIL-STD-810F, SAE-J1455, CCX
Device type	Tablet PC
Form factor	Slate
Product color	Grey, Silver
Protection features	Shock resistant, Vibration proof, Water resistant
International Protection (IP) code	IP66
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	62 mm
Width	318 mm
Height	260 mm
Weight	3000 g
