12 Thor VM3 with Microsoft Windows Embedded Compact 7 User Guide
VMXD Enhanced Dock
This dock is designed for use when the Thor VM3 is replacing a Thor VX8 or Thor VX9.
This dock utilizes the existing vehicle wiring from the earlier computer and supports
screen blanking through that wiring.
Note: For the VMX Enhanced Dock: COM1 is used for screen blanking (via the power cable
connector) and is unavailable when the screen blanking box is attached. When a screen
blanking box is attached, any external serial device such as a scanner, must be connected
to the COM2 port on the dock. If a screen blanking box is not connected via the power
cable, the COM1 port on the dock is available for a serial device.
Caution: This dock is designed for DC power vehicle-mounted
applications only.
SKUs VMX004VMCRADLE
Power
Connection
Designed to connect to existing Thor VX8 or Thor VX9 power cable only, using existing
DC/DC power supply
Serial Ports COM1 and COM2
(see note below)
USB Ports USB1 port provides host connection via an adapter cable. This port also supports
Honeywell external keyboards.
USB2 port provides two USB host ports via an adapter cable.
Direct USB host connection on top of dock.
Ethernet RJ-45 Ethernet connection on top of dock.
CANbus CANbus connection via an adapter cable
Audio Headset connection via an adapter cable
Screen
Blanking
Supported via power cable connector. (see note below)
Ignition
Control
Not supported

Honeywell Thor VM3 Specifications

General

Stepping	D0
Tjunction	-40 °C
FSB Parity	No
Processor code	SR1X8
Processor cache	1 MB
Processor cores	2
Processor model	E3826
System bus rate	- GT/s
Processor family	Intel Atom®
Processor codename	Bay Trail
Processor frequency	1.46 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor package size	25 x 27 mm
Conflict-Free processor	Yes
Processor front side bus	- MHz
Processor operating modes	32-bit, 64-bit
Graphics & IMC lithography	22 nm
PCI Express configurations	1x1, 1x4, 2x1
Thermal Design Power (TDP)	7 W
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
Storage media	Flash
Compatible memory cards	-
Internal storage capacity	64 GB
Display diagonal	12.1 \
Display brightness	900 cd/m²
Display resolution	1024 x 768 pixels
Graphics card	HD Graphics
Rear camera resolution (numeric)	- MP
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.0+EDR
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
HDMI ports quantity	0
USB 2.0 ports quantity	1
I/O ports	1x CAN-bus, RF
Processor ARK ID	78477
Processor socket	BGA 1170
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Platform	Windows
Bundled software	Data Collection Engine, Microsoft Internet Explorer, Microsoft on-screen keyboard, Configuration Cloning Utility, Screen Blanking, Zoom Zone, Launcher
Operating system installed	Windows 7
AC adapter input voltage	90 - 240 V
Battery capacity	- mAh
Battery life (max)	0.5 h
Certification	EN 55024:2010, MIL-STD-810F, SAE-J1455, CCX
Device type	Tablet PC
Form factor	Slate
Product color	Grey, Silver
Protection features	Shock resistant, Vibration proof, Water resistant
International Protection (IP) code	IP66
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	62 mm
Width	318 mm
Height	260 mm
Weight	3000 g
