Thor VM3 with Microsoft Windows Embedded Compact 7 User Guide 295
SPECIFICATIONS AND REFERENCE
MATERIAL
Technical Specifications
Thor VM3
Processor Intel Atom Dual Core CPU operating at 1.46GHz
Memory 2 or 4 GB DDR3 RAM
Mass Storage 2 GB mSATA
Storage Expansion 4 GB mSATA (user installable)
Operating System Microsoft Windows Embedded Compact 7
Radio Modules 802.11 a/b/g/n radio / Bluetooth
Scanner Options No integrated scanner, Optional serial, USB or Bluetooth scanners
Display Technology Intel HD graphics processor
Active matrix TFT
Resolution: 1024 x 468 pixels (maximum)
400 NIT (indoor) or 900 NIT (outdoor) brightness,
12.1” (measured horizontally) display
Transmissive with LED backlight
Automatic brightness control on outdoor display
Vehicle motion screen blanking available
Keyboard Integrated 7-key keypad
Optional 95-key USB keyboard
Optional numeric-only keyboard
Optional adapter cable for Honeywell PS/2 keyboards
Touch Screen Impact resistive, standard hardened
Optional defroster
Field replaceable front panel including touch screen and optional defroster
External Connectors Optional external 802.11 / GPS / WWAN antenna connectors
Additional connectors on dock, see below
Beeper Minimum loudness greater than 95dBm at 10 cm in front of unit
Power Supply 10 to 60 VDC isolated
Uninterruptible Power Supply Internal UPS battery, 30-minute life at -30°C (-22°F)
Backup Battery (RCT) Internal lithium battery maintains Real Time Clock

Honeywell Thor VM3 Specifications

General

Stepping	D0
Tjunction	-40 °C
FSB Parity	No
Processor code	SR1X8
Processor cache	1 MB
Processor cores	2
Processor model	E3826
System bus rate	- GT/s
Processor family	Intel Atom®
Processor codename	Bay Trail
Processor frequency	1.46 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor package size	25 x 27 mm
Conflict-Free processor	Yes
Processor front side bus	- MHz
Processor operating modes	32-bit, 64-bit
Graphics & IMC lithography	22 nm
PCI Express configurations	1x1, 1x4, 2x1
Thermal Design Power (TDP)	7 W
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
Storage media	Flash
Compatible memory cards	-
Internal storage capacity	64 GB
Display diagonal	12.1 \
Display brightness	900 cd/m²
Display resolution	1024 x 768 pixels
Graphics card	HD Graphics
Rear camera resolution (numeric)	- MP
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.0+EDR
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
HDMI ports quantity	0
USB 2.0 ports quantity	1
I/O ports	1x CAN-bus, RF
Processor ARK ID	78477
Processor socket	BGA 1170
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Platform	Windows
Bundled software	Data Collection Engine, Microsoft Internet Explorer, Microsoft on-screen keyboard, Configuration Cloning Utility, Screen Blanking, Zoom Zone, Launcher
Operating system installed	Windows 7
AC adapter input voltage	90 - 240 V
Battery capacity	- mAh
Battery life (max)	0.5 h
Certification	EN 55024:2010, MIL-STD-810F, SAE-J1455, CCX
Device type	Tablet PC
Form factor	Slate
Product color	Grey, Silver
Protection features	Shock resistant, Vibration proof, Water resistant
International Protection (IP) code	IP66
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	62 mm
Width	318 mm
Height	260 mm
Weight	3000 g
