150 Thor VM3 with Microsoft Windows Embedded Compact 7 User Guide
About
Start > Settings > Control Panel > About
The data cannot be edited by the Thor VM3 user on these panels.
Software
Firmware Versions
The Software tab lists the firmware versions installed. The BIOS, EC and Screen MCU
firmware versions are shown on this tab.
Language
The Software tab displays the localized language version of the OS image. The lan-
guage is identified as English only or + an additional language.
The languages are ordered separately and built-in to the OS image. The Thor VM3 may
be preloaded with an English only OS. Contact Technical Assistance for information on
installing an OS for a different language. The built-in languages are added to registry
entries and are available immediately upon startup.
Versions
The Versions tab displays the versions of many of the software programs installed. Not
all installed software is included in this list and the list varies depending on the applica-
tions loaded on the Thor VM3. The Image line displays the revision of the system soft-
ware installed. Refer to the last three digits to determine the revision level.
Tab Contents
Software GUID, Serial Number, Windows Embedded Compact Version, OAL Version, Compile Version,
and Language. Language indicates localized version.
Hardware CPU Type, Codec Type, Display, and DRAM memory
Versions Revision level of software modules and .NET Compact Framework Version.
Network IP Current network connection IP and MAC address.

Honeywell Thor VM3 Specifications

General

Stepping	D0
Tjunction	-40 °C
FSB Parity	No
Processor code	SR1X8
Processor cache	1 MB
Processor cores	2
Processor model	E3826
System bus rate	- GT/s
Processor family	Intel Atom®
Processor codename	Bay Trail
Processor frequency	1.46 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor package size	25 x 27 mm
Conflict-Free processor	Yes
Processor front side bus	- MHz
Processor operating modes	32-bit, 64-bit
Graphics & IMC lithography	22 nm
PCI Express configurations	1x1, 1x4, 2x1
Thermal Design Power (TDP)	7 W
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
Storage media	Flash
Compatible memory cards	-
Internal storage capacity	64 GB
Display diagonal	12.1 \
Display brightness	900 cd/m²
Display resolution	1024 x 768 pixels
Graphics card	HD Graphics
Rear camera resolution (numeric)	- MP
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.0+EDR
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
HDMI ports quantity	0
USB 2.0 ports quantity	1
I/O ports	1x CAN-bus, RF
Processor ARK ID	78477
Processor socket	BGA 1170
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Platform	Windows
Bundled software	Data Collection Engine, Microsoft Internet Explorer, Microsoft on-screen keyboard, Configuration Cloning Utility, Screen Blanking, Zoom Zone, Launcher
Operating system installed	Windows 7
AC adapter input voltage	90 - 240 V
Battery capacity	- mAh
Battery life (max)	0.5 h
Certification	EN 55024:2010, MIL-STD-810F, SAE-J1455, CCX
Device type	Tablet PC
Form factor	Slate
Product color	Grey, Silver
Protection features	Shock resistant, Vibration proof, Water resistant
International Protection (IP) code	IP66
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	62 mm
Width	318 mm
Height	260 mm
Weight	3000 g
