Thor VM3 with Microsoft Windows Embedded Compact 7 User Guide 23
Setup Terminal Emulation Parameters
The Thor VM3 offers both RFTerm and Enterprise TE. For details on configuring these
terminal emulators, refer to the appropriate user’s guide at www.honeywellaidc.com.
Cleaning
Cleaning the Thor VM3 and the Dock
Dampen a cloth with the cleaner and then wipe the surface. Do not spray the cleaner
directly onto the Thor VM3 or the dock. Avoid harsh chemicals. The following cleaners
are recommended:
• Windex® Glass Cleaner
• Formula 409® All-Purpose Cleaner or Glass and Surface Cleaner
• Fantastik® All Purpose Cleaner
• Liquid hand soap
Cleaning the Touch Screen
Note: These instructions are for components made of glass. If there is a removable protective
film sheet on the display, remove the film sheet before cleaning the screen.
Keep rough or sharp objects away from the Thor VM3 touch screen and, if installed, the
bar code reader scanning aperture.
If the glass becomes soiled or smudged, clean only with a standard household cleaner
such as Windex®
without vinegar or use isopropyl alcohol. Dampen the cloth with the
cleaner and then wipe the surface.
Do not use paper towels or harsh-chemical-based cleaning fluids since they may result
in damage to the glass surface. Use a clean, damp, lint-free cloth.
Do not scrub optical surfaces. If possible, clean only those areas which are soiled. Lint
and particulates can be removed with clean, filtered canned air.
Startup Help
Contact Technical Assistance if you need more help.
Thor VM3 seems to lockup as
soon as it is rebooted.
There may be slight delays while the wireless client connects to the
network, authorization for voice-enabled applications complete, and
Bluetooth relationships establish or re-establish.
When an application begins, the Thor VM3 is ready for use.

Honeywell Thor VM3 Specifications

General

Stepping	D0
Tjunction	-40 °C
FSB Parity	No
Processor code	SR1X8
Processor cache	1 MB
Processor cores	2
Processor model	E3826
System bus rate	- GT/s
Processor family	Intel Atom®
Processor codename	Bay Trail
Processor frequency	1.46 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor package size	25 x 27 mm
Conflict-Free processor	Yes
Processor front side bus	- MHz
Processor operating modes	32-bit, 64-bit
Graphics & IMC lithography	22 nm
PCI Express configurations	1x1, 1x4, 2x1
Thermal Design Power (TDP)	7 W
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
Storage media	Flash
Compatible memory cards	-
Internal storage capacity	64 GB
Display diagonal	12.1 \
Display brightness	900 cd/m²
Display resolution	1024 x 768 pixels
Graphics card	HD Graphics
Rear camera resolution (numeric)	- MP
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.0+EDR
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
HDMI ports quantity	0
USB 2.0 ports quantity	1
I/O ports	1x CAN-bus, RF
Processor ARK ID	78477
Processor socket	BGA 1170
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Platform	Windows
Bundled software	Data Collection Engine, Microsoft Internet Explorer, Microsoft on-screen keyboard, Configuration Cloning Utility, Screen Blanking, Zoom Zone, Launcher
Operating system installed	Windows 7
AC adapter input voltage	90 - 240 V
Battery capacity	- mAh
Battery life (max)	0.5 h
Certification	EN 55024:2010, MIL-STD-810F, SAE-J1455, CCX
Device type	Tablet PC
Form factor	Slate
Product color	Grey, Silver
Protection features	Shock resistant, Vibration proof, Water resistant
International Protection (IP) code	IP66
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	62 mm
Width	318 mm
Height	260 mm
Weight	3000 g
