Honeywell Thor VM3 User Manual

184 Thor VM3 with Microsoft Windows Embedded Compact 7 User Guide
Command
Options
Run cmd
Performs the command selected. For example, to run Netlog and modify the packet size
do the following:
1. Select load from the Commands list and click the Run cmd button.
2. Select stop from the Commands list and click the Run cmd button.
3. Select options from the Commands list, enter the new packet size in the Options list
and click the Run cmd button.
NDISLog
NDISLog creates a .TXT file that can be viewed with any text editor program that sup-
ports .TXT files.
Command Function
options Specifies the option to perform. See the table below for the option parameters and
values.
load Loads and starts Netlog.
start Starts the Netlog process of logging the network traffic.
stop Stops Netlog from logging network traffic.
unload Unloads Netlog.
Options Function
pkt_size
in bytes
Specifies the maximum packet size captured in bytes. This option should only be run after you
have called load and stop. Default is 5000.
cap_size
in bytes
Specifies the maximum size of Netlog0.cap or Netlog1.cap in bytes. This option should only
be run after you have called load and stop. Default is 500,000.
.cap file Specifies the name of the file to which network traffic information is saved. This option should
only be run after you have called load and stop. Default is \netlog.

Honeywell Thor VM3 Specifications

General

Stepping	D0
Tjunction	-40 °C
FSB Parity	No
Processor code	SR1X8
Processor cache	1 MB
Processor cores	2
Processor model	E3826
System bus rate	- GT/s
Processor family	Intel Atom®
Processor codename	Bay Trail
Processor frequency	1.46 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor package size	25 x 27 mm
Conflict-Free processor	Yes
Processor front side bus	- MHz
Processor operating modes	32-bit, 64-bit
Graphics & IMC lithography	22 nm
PCI Express configurations	1x1, 1x4, 2x1
Thermal Design Power (TDP)	7 W
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
Storage media	Flash
Compatible memory cards	-
Internal storage capacity	64 GB
Display diagonal	12.1 \
Display brightness	900 cd/m²
Display resolution	1024 x 768 pixels
Graphics card	HD Graphics
Rear camera resolution (numeric)	- MP
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.0+EDR
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
HDMI ports quantity	0
USB 2.0 ports quantity	1
I/O ports	1x CAN-bus, RF
Processor ARK ID	78477
Processor socket	BGA 1170
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Platform	Windows
Bundled software	Data Collection Engine, Microsoft Internet Explorer, Microsoft on-screen keyboard, Configuration Cloning Utility, Screen Blanking, Zoom Zone, Launcher
Operating system installed	Windows 7
AC adapter input voltage	90 - 240 V
Battery capacity	- mAh
Battery life (max)	0.5 h
Certification	EN 55024:2010, MIL-STD-810F, SAE-J1455, CCX
Device type	Tablet PC
Form factor	Slate
Product color	Grey, Silver
Protection features	Shock resistant, Vibration proof, Water resistant
International Protection (IP) code	IP66
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	62 mm
Width	318 mm
Height	260 mm
Weight	3000 g
