Honeywell UDC3200 User Manual

Input Calibration
ATTENTION
A restored factory calibration overwrites any previous field calibration done for the input and
may change the High and Low Range Limits.
Protect your field calibration from accidental overwrites by configuring the appropriate
LOCKOUT selection after calibration.
See Section 3 - Configuration for specific instructions to set the lockout.
Table 5-10 Restore Factory Calibration
Step Operation Press Result
1
Set LOCKOUT to
NONE
SetupSetup
until you see:
Upper Display = SET UP
Lower Display = TUNING
Function
FunctionFunction
Until you see:
Upper Display = one of the following:
NONE – all parameters are read/write
CALIB – all parameters are read/write except Calibration
+CONF – configuration parameters are Read Only; no
writes permitted
+VIEW – Tuning and Setpoint Ramp parameters are
read/write. No other parameters can be viewed.
ALL – Tuning and Setpoint Ramp parameters are available
for read only. No other parameters can be viewed.
Lower Display = LOCKOUT
or
Until NONE is in the upper display
2
Enter INPUT
Setup Group
SetupSetup
until you see:
Upper Display = SET UP
Lower Display = INPUT n n = 1 or 2
Function
FunctionFunction
until you see:
Upper Display = the current selection
Lower Display = INn TYPE
n = 1 or 2
or
to change the current selection to another selection
3
Scroll through
Functions
Function
FunctionFunction
until the lower display rolls through the rest of the functions and
returns to:
Upper Display = the new selection
Lower Display = INn TYPE
n = 1 or 2
or
until you change the input selection in the upper display back to the
proper selection. You will see:
Upper Display = Original Input Selection that matches your
type of sensor.
Lower Display = INn TYPE
n = 1 or 2
4
Return to Normal
Operation
Lower
Display
Lower
Display
Lower
Display
to return to Normal operating mode.
The factory calibration will be restored. If the problem is not
corrected, contact the Honeywell Technical Assistance Center at 1-
800-423-9883 USA and Canada
142 UDC3200 Universal Digital Controller Product Manual 12/04
