Troubleshooting/Service
Procedure #9
Table 7-13 explains how to troubleshoot an Ethernet Communications failure.
Table 7-13 Troubleshooting an Ethernet Communications Failure
Step What to do How to do it
1
Check the IP address, Subnet
Mask address and Gateway
address settings.
See the PIE Tool Manual.
2
Check if the Ethernet Connection
is active.
Looking into the instrument, there should be steady
green LED. If this is not present, then the
instrument is not seeing a valid Ethernet
connection. See Section 2.7 for wiring diagrams. A
second green LED will blink during actual Ethernet
transactions.
3
Change Ethernet
Communications board.
Installation instructions provided with new
board.
4
Change Controller
168 UDC3200 Universal Digital Controller Product Manual 12/04
