Modbus Read, Write and Override Parameters plus Exception Codes
10.7.5 Output Algorithms
Table 10-13 lists all the register addresses and ranges or selections for the function
parameters in Set-up Group Output.
Table 10-13 Set-up Group – Output
Parameter
Description
Register
Address
Data
Type
Access Data Range or
Enumerated Selection
Hex Decimal
Output
Algorithm
00A0 160 INT
3 = Time Duplex
R/W 0 = Time Simplex
1 = Current Simplex
2 = Three Position Step or
Position Proportioning
4 = Current Duplex
5 = Current/Time Duplex
6 = Time/Current Duplex
Relay Cycle
Time
Increments
00BE 190 INT R/W 0 = 1 second increments
1 = 1/3 second increments
Motor Time for
Positional
Proportional
004B 075 INT R/W 5 to 1800 seconds
Relay Output
Action
00F3 243 INT R/W
0 = 1 OFF 2 OFF
3 = 1 ON 2 ON
1 = 1 ON 2 OFF
2 = 1 OFF 2 ON
Current Range
for Current
Duplex
0099 153 INT R/W
0 = Full (100%)
1 = Split (50%)
Current Output
(Auxiliary
Output Mode)
00F2 242 INT R/W
0 = Disable
1 = Input 1
2 = Input 2
3 = PV
4 = Deviation
5 = Output
6 = SP
7 = LSP
8 = RSP
9 = Input Algorithm 1
Current Output
Range
00EA 235 INT R/W
0 = 4-20 mA
1 = 0-20 mA
12/04 UDC3200 Universal Digital Controller Product Manual 201
