Configuration
Function Prompt Selections or
Parameter
Lower Display
Range of Setting
Upper Display
Definition
SP PROG
(optional feature)
SP Ramp must be
disabled for SP
Program prompts to
appear. If SP Rate is
enabled, it does not
operate while an SP
Program is running.
DISABLE
ENABLE
SETPOINT RAMP/SOAK PROGRAM—Available
only with controllers that contain this option.
SP RAMP must be disabled.
DISABLE—Disables setpoint programming.
ENABLE—Enables setpoint programming.
ATTENTION Detailed information for the prompts
for SP Programming may be found Section 4.17 The
listing below is only for reference purposes.
STRT SEG
1 to 11 Start Segment Number
END SEG
2 to 12 even numbers
Always end in a soak
segment
(2, 4, ... 12)
End Segment Number
RAMPUNIT
TIME
EU/MIN
EU/HR
RAMPUNIT—Engineering Units for Ramp Segments
TIME in hours: minutes
RATE in Enineering units per minute
RATE in Enineering units per hour
RECYCLES
0 to 99 recycles Number of Program Recycles
SOAK DEV
0 to 99
The number selected will
be the PV value (in
engineering units) above
or below the setpoint
outside of which the timer
halts.
Guaranteed Soak Deviation Value
PROG END
LASTSP (Hold at last
setpoint in the program)
F SAFE (Manual
mode/Failsafe output)
Program Termination State
STATE
DISABLE
HOLD
Program State at Program End
KEYRESET
DISABLE
ToBEGIN
RERUN
Reset/Rerun SP Program
HOTSTART
DISABLE
ENABLE
Hot Start
SEG1RAMP or
SEG1RATE
0-99 hours.0-59 minutes
Engineering units/minute
or
Engineering units/hour
Segment #1 Ramp Time or
Segment #1 Ramp Rate
Select TIME, EU/MIN, or EU/HR at prompt
RAMPUNIT. All ramps will use the same
selection.
