254
# Configure Router B.
[RouterB] bgp 65009
[RouterB-bgp] router-id 2.2.2.2
[RouterB-bgp] peer 3.1.1.2 as-number 65008
[RouterB-bgp] address-family ipv4 unicast
[RouterB-bgp-ipv4] peer 3.1.1.2 enable
4. Configure BGP and IGP route redistribution:
# Configure route redistribution between BGP and OSPF on Router B.
[RouterB-bgp-ipv4] import-route ospf 1
[RouterB-bgp-ipv4] quit
[RouterB-bgp] quit
[RouterB] ospf 1
[RouterB-ospf-1] import-route bgp
[RouterB-ospf-1] quit
# Display the BGP routing table on Router A.
[RouterA] display bgp routing-table ipv4
Total number of routes: 3
BGP local router ID is 1.1.1.1
Status codes: * - valid, > - best, d - damped, h - history,
s - suppressed, S - Stale, i - internal, e - external
Origin: i - IGP, e - EGP, ? - incomplete
Network NextHop MED LocPrf PrefVal Path/Ogn
* >e 3.3.3.3/32 3.1.1.1 1 0 65009?
* > 8.1.1.0/24 8.1.1.1 0 0 i
* >e 9.1.2.0/24 3.1.1.1 1 0 65009?
# Display the OSPF routing table on Router C.
[RouterC] display ospf routing
OSPF Process 1 with Router ID 3.3.3.3
Routing Tables
Routing for Network
Destination Cost Type NextHop AdvRouter Area
9.1.1.0/24 1 Transit 9.1.1.2 3.3.3.3 0.0.0.0
2.2.2.2/32 1 Stub 9.1.1.1 2.2.2.2 0.0.0.0
Routing for ASEs
Destination Cost Type Tag NextHop AdvRouter
8.1.1.0/24 1 Type2 1 9.1.1.1 2.2.2.2
Total Nets: 3
Intra Area: 2 Inter Area: 0 ASE: 1 NSSA: 0
