367
<RouterA> display bfd session
Total Session Num: 1 Up Session Num: 1 Init Mode: Active
IPv6 Session Working Under Ctrl Mode:
Local Discr: 1441 Remote Discr: 1450
Source IP: FE80::20F:FF:FE00:1202 (link-local address of Ethernet1/1 on Router
A)
Destination IP: FE80::20F:FF:FE00:1200 (link-local address of Ethernet1/1 on Router
B)
Session State: Up Interface: Eth1/1
Hold Time: 2319ms
# Display routes destined for 2001:4::0/64 on Router A.
<RouterA> display ipv6 routing-table 2001:4::0 64
Summary Count : 1
Destination: 2001:4::/64 Protocol : OSPFv3
NextHop : FE80::20F:FF:FE00:1200 Preference: 10
Interface : Eth1/1 Cost : 1
The output shows that Router A communicates with Router B through Ethernet 1/1. Then the link over
Ethernet 1/1 fails.
# Display routes destined for 2001:4::0/64 on Router A.
<RouterA> display ipv6 routing-table 2001:4::0 64
Summary Count : 1
Destination: 2001:4::/64 Protocol : OSPFv3
NextHop : FE80::BAAF:67FF:FE27:DCD0 Preference: 10
Interface : Eth1/2 Cost : 2
The output shows that Router A communicates with Router B through Ethernet 1/2.
Configuring OSPFv3 IPsec profiles
Network requirements
As shown in Figure 91, all routers run OSPFv3, and the AS is divided into two areas.
Configure IPsec profiles on the routers to authenticate and encrypt protocol packets.
