17
[RouterB] bfd multi-hop min-transmit-interval 500
[RouterB] bfd multi-hop min-receive-interval 500
[RouterB] bfd multi-hop detect-multiplier 9
[RouterB] ip route-static 121.1.1.0 24 1.1.1.9 bfd control-packet bfd-source 2.2.2.9
[RouterB] ip route-static 121.1.1.0 24 ethernet 1/2 13.1.1.2 preference 65
[RouterB] quit
# Configure static routes on Router C.
<RouterC> system-view
[RouterC] ip route-static 120.1.1.0 24 13.1.1.1
[RouterC] ip route-static 121.1.1.0 24 10.1.1.102
# Configure static routes on Router D.
<RouterD> system-view
[RouterD] ip route-static 120.1.1.0 24 11.1.1.2
[RouterD] ip route-static 121.1.1.0 24 12.1.1.1
Verifying the configuration
# Display the BFD session information on Router A.
<RouterA> display bfd session
Total Session Num: 1 Up Session Num: 1 Init Mode: Active
IPv4 Session Working Under Ctrl Mode:
LD/RD SourceAddr DestAddr State Holdtime Interface
4/7 1.1.1.9 2.2.2.9 Up 2000ms N/A
The output shows that the BFD session has been created.
# Display static routes on Router A.
<RouterA> display ip routing-table protocol static
Summary Count : 1
Static Routing table Status : <Active>
Summary Count : 1
Destination/Mask Proto Pre Cost NextHop Interface
120.1.1.0/24 Static 60 0 12.1.1.2 Eth1/1
Static Routing table Status : <Inactive>
Summary Count : 0
The output shows that Router A communicates with Router B through Ethernet 1/1. Then the link over
Ethernet 1/1 fails.
# Display static routes on Router A.
<RouterA> display ip routing-table protocol static
Summary Count : 1
Static Routing table Status : <Active>
