47
[RouterA-rip-1] version 2
[RouterA-rip-1] undo summary
[RouterA-rip-1] network 192.168.1.0
[RouterA-rip-1] quit
[RouterA] interface ethernet 1/1
[RouterA-Ethernet1/1] rip bfd enable
[RouterA-Ethernet1/1] quit
[RouterA] rip 2
[RouterA-rip-2] network 192.168.2.0
[RouterA-rip-2] quit
# Configure Router B.
<RouterB> system-view
[RouterB] rip 1
[RouterB-rip-1] version 2
[RouterB-rip-1] undo summary
[RouterB-rip-1] network 192.168.2.0
[RouterB-rip-1] network 192.168.3.0
[RouterB-rip-1] quit
# Configure Router C.
<RouterC> system-view
[RouterC] rip 1
[RouterC-rip-1] version 2
[RouterC-rip-1] undo summary
[RouterC-rip-1] network 192.168.1.0
[RouterC-rip-1] network 192.168.3.0
[RouterC-rip-1] import-route static
[RouterC-rip-1] quit
2. Configure the BFD parameters on Ethernet 1/1 of Router A.
[RouterA] bfd session init-mode active
[RouterA] bfd echo-source-ip 11.11.11.11
[RouterA] interface ethernet 1/1
[RouterA-Ethernet1/1] bfd min-transmit-interval 500
[RouterA-Ethernet1/1] bfd min-receive-interval 500
[RouterA-Ethernet1/1] bfd detect-multiplier 7
[RouterA-Ethernet1/1] return
3. Configure a static route on Router C.
[RouterC] ip route-static 120.1.1.1 24 null 0
Verifying the configuration
# Display the BFD session information on Router A.
<RouterA> display bfd session
Total Session Num: 1 Up Session Num: 1 Init Mode: Active
IPv4 Session Working Under Echo Mode:
LD SourceAddr DestAddr State Holdtime Interface
4 192.168.1.1 192.168.1.2 Up 2000ms Eth1/1
