HP 9020 User Manual

4-62 Assembly Access
6. Remove three #2 Pozidriv screws that attach top cover to ac module (Figure 4-64), and
remove cover.
*
* #2 POZIDRIV SCREW *
Figure 4-64. Removing Ac Module Cover
7. Disconnect two line filter wires from power switch assembly lugs (Figure 4-65). Note that
blue wire is on top lug and brown wire on bottom lug.

HP 9020 Specifications

General

Brand	HP
Model	9020
Category	Desktop
Language	English
