IPv4 Access Control Lists (ACLs)
Configuring and Assigning an IPv4 ACL
ip access-list extended < identifier >
[ [ seq-# ] remark < remark-str >]
< permit | deny > < ipv4-protocol-type > < SA > < src-acl-mask > < DA > <dest-acl-mask > [log]
< permit | deny > tcp
< SA > < src-acl-mask > [< operator > < port-id >]
< DA > < desti-acl-mask > [< operator > < port-id >] [log]
[ established ]
Note: The optional log
function is available
only for “deny” ACEs.
< permit | deny > udp
< SA > < src-acl-mask > [< operator > < port-id >]
< DA > < dest-acl-mask > [< operator > < port-id >] [log]
< permit | deny > icmp
< SA > < src-acl-mask > < DA > < dest-acl-mask > [ icmp-type ] [log]
< permit | deny > igmp
< SA > < SA-mask > < DA > < dest-acl-mask > [ igmp-type ] [log]
[ precedence < priority >]
[ tos < tos-setting >]
. . .
< Implicit Deny >
exit
Figure 9-8. Example of General Structure Options for an Extended ACL
