HP PROCURVE 2910AL User Manual

IPv4 Access Control Lists (ACLs)
Configuring Extended ACLs
Options for TCP and UDP Traffic in Extended ACLs. An ACE designed
to permit or deny TCP or UDP traffic can optionally include port number
criteria for either the source or destination, or both. Use of TCP criteria also
allows the established option for controlling TCP connection traffic. (For a
summary of the extended ACL syntax options, refer to table 9-7 on page 9-53.)
Syntax: < deny | permit > < tcp | udp >
< SA > [comparison-operator < tcp/udp-src-port >]
< DA >
[comparison-operator < tcp-dest-port >] [established]
[comparison-operator < udp-dest-port >]
In an extended ACL using either tcp or udp as the packet protocol
type, you can optionally use TCP or UDP source and/or desti-
nation port numbers or ranges of numbers to further define the
criteria for a match. For example:
#
deny tcp host 10.20.10.17 eq 23 host 10.20.10.155
established
#permit tcp host 10.10.10.100 host 10.20.10.17
eq telnet
#deny udp 10.30.10.1/24 host 10.20.10.17 range
161 162
[comparison-operator < tcp/udp-src-port >]
To specify a TCP or UDP source
port number in an ACE, (1)
select a comparison operator from the following list and (2)
enter the port number or a well-known port name.
Comparison Operators:
• eq < tcp/udp-port-nbr > — “Equal To”; to have a match with the
ACE entry, the TCP or UDP source port number in a packet
must be equal to < tcp/udp-port-nbr >.
• gt < tcp/udp-port-nbr > — “Greater Than”; to have a match with
the ACE entry, the TCP or UDP source port number in a
packet must be greater than < tcp/udp-port-nbr >.
• lt < tcp/udp-port-nbr > — “Less Than”; to have a match with the
ACE entry, the TCP or UDP source port number in a packet
must be less than < tcp/udp-port-nbr >.
• neq < tcp/udp-port-nbr> — “Not Equal”; to have a match with
the ACE entry, the TCP or UDP source port number in a
packet must not be equal to < tcp/udp-port-nbr >.
• range < start-port-nbr > < end-port-nbr > — For a match with the
ACE entry, the TCP or UDP source-port number in a packet
must be in the range <start-port-nbr >
< end-port-nbr >.
9-61

HP PROCURVE 2910AL Specifications

General

Model	HP ProCurve 2910al
Switching Capacity	128 Gbps
Throughput	95.2 Mpps
Management	Web, CLI, SNMP
Jumbo Frame Support	Yes
Manageable	Yes
Power	100-240 VAC
Power Supply	Internal
Operating Temperature	0°C to 45°C (32°F to 113°F)
Stacking	Yes
MAC Address Table Size	32000 entries
Routing Protocol	RIP, OSPF
Features	IPv6, VLAN, QoS, ACLs
Operating Humidity	15% to 95% non-condensing
Uplink Ports	4
Power over Ethernet	Yes (PoE+ models available)
