Using Authorized IP Managers
Defining Authorized Management Stations
ProCurve(config)# ip authorized-managers 10.10.10.2 255.255.255.255 manager
Figure 14-4. Example of Configuring IP Authorized Manager
To Authorize Manager Access. This command authorizes manager-level
access for any station with an IP address of 10.28.227.0 through 10.28.227.255:
ProCurve(conf
ig)# ip authorized-managers 10.28.227.101
255.255.255.0 access manager
Similarly, the next command authorizes manager-level access for any station
having an IP address of 10.28.227.101 through 103:
ProCurve(config)# ip authorized-managers 10.28.227.101
255.255.255.252 access manager
If you omit the < mask bits > when adding a new authorized manager, the switch
automatically uses 255.255.255.255. If you do not specify either Manager or
Operator access, the switch assigns the Manager access.
To Edit an Existing Manager Access Entry. To change the mask or
access level for an existing entry, use the entry’s IP address and enter the new
value(s). (Notice that any parameters not included in the command will be set
to their default.):
ProCurve(config)# ip authorized-managers
10.28.227.101 255.255.255.0 access operator
The above command replaces the existing mask and access level for IP
address 10.28.227.101 with 255.255.255.0 and operator.
The following command replaces the existing mask and access level for IP
address 10.28.227.101 with 255.255.255.255 and manager (the defaults)
because the command does not specify either of these parameters.
ProCurve(config)# ip authorized-managers 10.28.227.101
To Delete an Authorized Manager Entry. This command uses the IP
address of the authorized manager you want to delete:
ProCurve(config)# no ip authorized-managers 10.28.227.101
14-7
