Memory
• The hardware installation and configuration poster that ships with the server
•
•
•
•
The hardware installation and configuration labels located on the top of the front
and rear access panels of the server
For more information on configuring the memory through the RBSU, refer to the
ROM-Based Setup Utility User Guide on the Documentation CD.
Memory Boards
The ProLiant DL580 Generation 2 server can support up to two memory boards to
either expand system memory or to enable dual-board mirroring memory and
hot-plug capabilities.
This section provides the following information about the memory boards:
Parts of the memory board
Memory board LEDs
Memory board slot locations
