PCI-X Technology

CAUTION: Do not attempt this hot-plug operation if the operating system does

not provide PCI-X Hot Plug support or if you do not have the appropriate device

drivers installed. Failure to properly execute a hot-plug operation can halt the

system.

5. Press the port PCI-X Hot Plug button or use the PCI-X Hot Plug Utility to power

down the PCI-X Hot Plug slot.

CAUTION: Be sure that the slot LED is off before installing the expansion board.

Figure 7-7: Powering down the slot with the PCI-X Hot

Plug button

HP ProLiant DL580 Generation 2 Server Setup and Installation Guide 7-13

HP CONFIDENTIAL

Writer: Karen Hale File Name: h-ch7 PCI-X Technology.doc

Codename: Wave Part Number: 230835-003 Last Saved On: 6/26/03 9:38 AM
