Planning the Server Installation

This chapter provides information and instructions for planning the installation of the

new HP ProLiant DL580 Generation 2 server. Figure 4-1 illustrates multiple ProLiant

DL580 Generation 2 servers installed in a rack.

Figure 4-1: ProLiant DL580 Generation 2 servers

installed in a rack

The following sections describe the server and site preparations required to correctly

and safely install the server. This preparation includes:

•

Optimum environment considerations

Rack planning resources

Rack warnings and cautions

HP ProLiant DL580 Generation 2 Server Setup and Installation Guide 4-1

HP CONFIDENTIAL

Writer: Karen Hale File Name: e-ch4 Planning the Server Installation.doc

Codename: Wave Part Number: 230835-003 Last Saved On: 6/26/03 9:28 AM
