Memory

Use Figure 6-3 and Table 6-6 to identify the memory board slots on the system

board.

Figure 6-3: Memory board slots

Table 6-6: Memory Board Slots

Item Description

1 Memory board slot 1

2 Memory board slot 2

6-8 HP ProLiant DL580 Generation 2 Server Setup and Installation Guide

HP CONFIDENTIAL

Writer: Karen Hale File Name: g-ch6 Memory.doc

Codename: Wave Part Number: 230835-003 Last Saved On: 6/26/03 9:35 AM
