HP Proliant DL580 Setup And Installation Guide

System LEDs and Switches
Table E-9: Online Spare Memory Mode
Item Description Indicator Status
Off Bank is not configured as an online spare bank.
Green Bank is configured as an online spare bank.
5 Online Spare
text
Flashing green Failure has occurred and online spare bank is active.
Off Memory board is offline.
Green Memory board is online.
Flashing green Memory board is busy.
6 Memory
Status
Amber Memory error has occurred on this memory board.
7 Ready to Hot
Plug
Off Do not remove memory board—online spare memory
does not support hot-plug capability.
Off Memory board is not configured for online spare
memory.
Green Online spare memory is functioning properly.
8 Online spare
Status
Amber Memory error has occurred and system has failed over
to the online spare bank.
Off Memory board is not seated properly or locking switch is
not engaged; memory board can be removed safely.
All LEDs
Flashing amber
CAUTION: Memory board is in use; relock it
immediately.
E-10 HP ProLiant DL580 Generation 2 Server Setup and Installation Guide
HP CONFIDENTIAL
Writer: Karen Hale File Name: p-appe System LEDs and Switches3.doc
Codename: Wave Part Number: 230835-003 Last Saved On: 6/26/03 9:49 AM
