HP Proliant DL580 - Extending the Server from the Rack

To Next Page

To Previous Page

Installing Hardware Options

2. Extend the server on the rack rails until the server rail-release latches engage.

Figure 5-5: Extending the server from the rack

WARNING: Be careful when pressing the rail-release levers and sliding the

component into or out of the rack. The sliding rails could pinch your fingertips.

5-10 HP ProLiant DL580 Generation 2 Server Setup and Installation Guide

HP CONFIDENTIAL

Writer: Karen Hale File Name: f-ch5 Installing Hardware Options.doc

Codename: Dwarf Part Number: 230835-003 Last Saved On: 6/26/03 9:31 AM
