Cabling 89
Item
Description
Quantity
4
LED board power and signal
cable
LED board J1 to CPLD board J10 (x 1)
5
CPLD board power cable
Power interposer board J11 to CPLD board J4 (x 1)
6
HDD 1-4 power and signal
cable
Power interposer board J4 to HDD 1-4 (x 1)
7
HDD 5-8 power and signal
cable
Power interposer board J6 to HDD 5-8 (x 1)
8
HDD 9-12 power and signal
cable
Power interposer board J5 to HDD 9-12 (x 1)
9
Fan control board power cable
Power interposer board J9 to fan control board J19, J20, J21 (x 1)
10
CPLD board signal cable
Power interposer board J15 and CPLD board J2 to fan control
board J3 (x 1)
11
UID LED cable
System board to front/rear of chassis (x 1)
