09/01/13www.HandiQuilter.com Installaon | 3.15
7. With the computer installed in the bracket, connect
the USB short cable (see Parts List, item M) between
the USB port, on the top-le side of the computer
(posion A) and the black box on the back of the
bracket (posion E).
8. Also connect the computer power cord (see Parts List,
item N) between the computer (posion B) and the
black box (posion C).
9. The open USB ports on the black box (posion F) are
for plugging in the USB Flash drive to load designs or
update the soware, or for plugging in a keyboard or
mouse.
A
B
C D E
F
